As a standalone system or connected to an existing dealer management system (DMS) – the TMS smart family, combined with our myTecalemit fill level monitoring, offers you the most modern oil inventory monitoring and dispensing system currently available on the market.
Your Advantages at a Glance:
- One system for both mobile and stationary applications
- Simple installation process
- Fast and easy operation for efficiency
- Precise measurement and dispensing for accurate inventory management
- Full control via “TMS smart Control” software
- Fast payback with price advantage over conventional systems
- Easy integration into existing systems for seamless operation
Technical specifications:
- Viscosity range: 20 – 2000 mPa s
- Smallest volume flow (Q min): 0.2 gpm
- Largest volume flow (Q max): +/- 2.5 gpm
- Max. Operating pressure (p): 70 bar
- Threaded connection: G 1/2’’ internal
- Measuring accuracy: +/- 1% (+/-0.5% following calibration)
- Weight: 3.7 Lbs
- IP protection: IP54
- Permitted operating temperature: 14°F to +131°F
- Permitted storage temperature: -4°F to +158°F
Compatible products:
- Authorized liquids: Engine oil, gear oil, hydraulic oil, radiator antifreeze, diesel, heating oil
