The new TecSonic follows the same hardware design language that speaks quality for the best monitoring and reporting experience. This design takes less than 5 minutes to install and this new platform has expanded to be able to work with the proven MyTECALEMIT Cloud Fuel Management Platform as well as the added capability to be deployed and implemented as a stand alone solution.

The new range of Ultrasonic, wireless tank level controller devices run on a 4G network offering reliable, cost effective solutions across a range of petroleum based products. We can help access real-time data facilitating smarter decision-making for your business.

Dimensions ( W x D x H): 4” x 3.66” x 5.9” ±0.04
Weight: 1.17lbs
Housing Material: UV Stabilized Polypropylene (Compatible with Oil)
Operating Temperature: -4°F to 122°F
Storage Temperature: 30°C to 60°C / -22°F to 140°F
Altitude Range: <2Km/1.25miles above sea level Environmental Protection: IP67 — Outdoors Gauge Type: Ultra Sonic Ultrasonic Range: >4.7” to 157”
Accuracy: ±0.78” from 4.7” to 118”
Power Requirements: 4 of Type C LR14 Alkaline 1.5V (fitted)
SIM Card: Included
Tank mounting options: Fit directly into 1 1/2” or 2” BSP existing tank
13 feet max height
Accuracy: ±0.78” from 4.7” to 118”
Compatibility: Diesel Fuel, Lube Oil, DEF, Coolant

Water
Diesel
DEF
Coolant
Lube Oil
