The new TecSonic Ex-proof bundle consists of a Class I logger and a Class I level probe. This new platform has expanded to be able to work with the proven MyTECALEMIT Cloud Platform. TecSonic Ex-Proof has the added capability to be deployed and implemented as a stand alone solution. This new range of Ultrasonic devices boast generation 6.0 AI echo intelligence, selecting the best returned resonance for an accurate measurement.

Dimensions:
4.331”W x 4.91”H x 2.375”D (logger)
4.56”L x 0.91” Dia (probe)

Operating Temperature:
Probe: -4˚F to 176˚F (-20˚C to 80˚C)
Logger: -22˚F to 131˚F (-30˚C to 55˚C)

Maximum tank height: 13 feet (3.96m)
Maximum level probe cable: 16 feet (4.87m)
Housing Material: UV Stabilized Polypropylene
Environmental Protection: IP68
Type: Logger & Level Probe
Accuracy: max ±2% of FS
Power: 3.6V Lithium Thionyl Chloride Exi “Bobbin type” construction
SIM Card: Included
Tank mounting options: 2” FNPT x 1” FNPT
Humidity: 0-100% RH
Compatibility: Gasoline
Simple over the air update
Ongoing research and development for the next AI generation

TecSonic Ex-Proof — TecSonic Explosion Proof Spec Sheet

TecSonic Ex-Proof — TecSonic Explosion Proof Full Installation and Set-up Guide
